ksim

K-Scale's Mujoco-based framework for training policies in simulation

Welcome to ksim, K-Scale's Mujoco-based framework for training policies in simulation.

See the framework source code on Github.

Getting Started

To install ksim, simply run:

pip install ksim

Make sure you have installed Jax correctly for your system.

We recommend using conda instead of uv as a virtual environment manager for now, because we've observed weird issues with mjpython with uv on MacOS.

After installation, run one of our example scripts .

Variable Naming Conventions

We try to follow Noam Shazeer's variable naming conventions where possible.

Please use these units in the suffixes of variable names. For PyTrees, assume consistency of all dimensions except L. If including the timestamp would help someone understand the variable, do the dimension suffix first, then the timestamp suffix. (e.g. mjx_data_L_0). If it helps, specify return units in function docstrings.

Dimension suffixes:

  • D: dimension of environment states in the dataset.
  • B: dimension of environment states in each minibatch.
  • T: the time dimension during rollout.
  • E: the env dimension during rollout.
  • L: leaf dimension of a pytree (e.g. joint position vector size in an obs), should not be used if the variable's final dimension is a scalar.

Timestamp suffixes:

  • t: current timestep
  • t_plus_1: next timestep
  • t_minus_1: previous timestep
  • t_0: initial timestep
  • t_f: final timestep

These should absolutely be annotated:

  • mjx.Data
  • mjx.Model
  • Everything relevant to Trajectory (e.g. obs, command, action, etc.)

Troubleshooting

Headless Systems

When you try to render a trajectory while on a headless system, you may get an error like the following:

mujoco.FatalError: an OpenGL platform library has not been loaded into this process, this most likely means that a valid OpenGL context has not been created before mjr_makeContext was called

The fix is to create a virtual display:

Xvfb :100 -ac &
PID1=$!
export DISPLAY=:100.0

You may also need to tell MuJoCo to use GPU accelerated off-screen rendering via

export MUJOCO_GL="egl"

NaNs when running example policy

This manifests sometimes when you have an error like this:

Registers are spilled to local memory in function

We have observed this happening when training on RTX 4090s. To mitigate, disable Triton GEMM kernels:

export XLA_FLAGS='--xla_gpu_enable_latency_hiding_scheduler=true --xla_gpu_enable_triton_gemm=false'

Then, you may need to remove your JAX cache to trigger JAX to rebuild the kernels:

rm -r ~/.cache/jax/jaxcache

We've found that removing the cache can fix a number of otherwise-mysterious errors.

NaNs during training

Seeing NaNs when training a new policy is always frustrating. We have implemented a few tools in ksim to help debug such NaNs. Here is our suggested workflow:

  1. Make sure you are regularly saving checkpoints.
  2. When you start seeing NaNs, kill your training job.
  3. Re-run the training job initializing from the same checkpoint
JAX_DEBUG_NANS=True DISABLE_JIT_LEVEL=10 python -m examples.walking exp_dir=/path/to/exp/dir/run_N

This will disable JIT'ting the training pass of your neural network while keeping the MJX environment step JIT'ted, while also throwing an error the first time that JAX encounters a NaN.
